Museum Plus Base Recessed
10039
INDOOR
RECESSED
DIMMABLE
CASAMBI
WIRELESS
| Installation | Indoor | |
| Mounting Position | Track | |
| IP | 20 | |
| Wattage | 12,3W | 23,6W |
| Lumen output | 1600 | 3300 |
| Connection | 350mA | 700mA |
| Driver | Not included | |
| Dimmable | ON/OFF, DALI, PUSH (See drivers section) |
| CRI | >90 |
| Life Time | L80/B10 >55.000 h |
| Cut-out Size | Ø70 h60mm |
| Dimmensions | Ø93 h90mm |
| Adjustable | Yes |
10039.**.**.*.**.XXX
| Number | W | Colour Temperature | Light Distribution | Finish | Dim |
|---|---|---|---|---|---|
| 10039 | 12 | 27 2700K |  1 Narrow 12º |  10 White | XXX Driver not included (See drivers section) |
| 24 | 30 3000K |  2 Medium 25º |  20 Black | ||
| 40 4000K |  3 Wide 36º | Other finishes available upon request |
20022.A.1.20 Asymmetric cowl
20022.A.2.20 Symmetric cowl
20022.A.3.20 Barn doors
20022.A.4.20 Oval lens
20022.A.5.20 Spread lens
20022.A.6.20 Honeycomb Louvre
Black
