Curriculum-f 90 HE
10043
INDOOR
RECESSED
ALEXA, SIRI, GOOGLE
DIMMABLE
CASAMBI
WIRELESS
| Installation | Indoor |
| Mounting Position | Ceiling recessed |
| IP | 20 |
| Driver | Not included |
| Dimmable | ON/OFF, DALI, PUSH |
| CRI | >90 |
| Life Time | L80/B10 >55.000 h |
| Cut-out Size | Ø80 mm |
| Adjustable | +/- 20º |
| Wattage | 5W |
| Lumen Output | 750 |
| Connection | 150mA |
| Dimensions | Ø90 h84mm |
| Cut-out Size | Ø80 h94mm |
| Wattage | 8,6W |
| Lumen Output | 1200 |
| Connection | 250mA |
| Dimensions | Ø90 h111mm |
| Cut-out Size | Ø80 h121mm |
10043.*.**.*.**.XXX
| Number | W | Colour Temperature | Light Distribution | Finish | Dim |
|---|---|---|---|---|---|
| 70043 | 5 | 27 2700K |  1 Narrow 15º |  10 White | XXX Driver not included |
| 9 | 30 3000K |  2 Medium 25º | |||
| 40 4000K |  3 Wide 39º | ||||
 4 Superwide 61º |
10001.A.20.99 Spread lens
10001.A.10.99 Oval lens
10001.A.30.99 Honeycomb Louvre
